Plasmon LIBRARIES D2175 User Manual
Page 83
Plasmon D875 - D2175 User Manual
Appendix D
Document Revision E
Page 81
4
Time out for flipper
home CCW command
5
Time out for flipper
home CW command
6
Time out for flipper step
CW command
7
Time out for flipper step
CW command
8
Time out for flip to CCW
command
9
Time out for flip to CW
command
10
Time out for fliptest
command
11
Time out for flipper read
EEPROM command
12
Time out for flipper
write EEPROM com-
mand
13
Time out for flipper
unlock EEPROM com-
mand
14
Time out for flipper lock
EEPROM command
21
Command resent to
flipper 3 times, flipper
NAK'd
22
Comm error on status
command to flipper
23
No ACK from flipper,
command resent 3
times
B7
21
Flipper power
reset
Flipper to mag interface
comm err, SNAK bit for
power-up bitmask
Flipper
Replace flipper
22
Flipper to mag inter-
face, comm err, SNAK
bit for brown-out bit-
mask
Error
Code
(hex)
Sub-
code
Error
Description
Subcode
Description
Compo-
nent
Corrective Action
