Plasmon D875 - D2175 User Manual Appendix D
Document Revision E Page 77
6A 1 Pivot Fail Pivot is loosing posi-
tion accuracy, not on
alignment flag verifying
pivot position Offsets Run offsets
2 Outside allowed pivot
soft deviation steps, but
position will succeed
3 Outside allowed pivot
soft deviation steps, but
position will succeed
4 Outside allowed pivot
hard deviation steps,
position will fail
5 Destination pivot value
out of range
6 Pivot position failed to
be reached (time out)
70 1 Mag door open
fail Time out waiting for
mag door status Mag inter-
face circuit
board, mag
solenoid Replace Mag circuit board or
solenoid, check mechanical
obstruction
71 1 Mag access
door is open Mag door open during
initialization Close door
2 Mag door opened in
online mode (not by
solenoid)
72 1 Door open pre-
vented SCSI prevent com-
mand was issued by
host, mag door opening
is not allowed Issue SCSI allow from host
74 1 Rear door is
open Background check of
rear door open during
initialization Close Rear door
2 Background check of
rear door open during
online operation
3 Rear door open during
online test ready check
Error
Code
(hex)
Sub-
code
Error
Description
Subcode
Description
Compo-
nent
Corrective Action
