Plasmon LIBRARIES D2175 User Manual
Page 69
Plasmon D875 - D2175 User Manual
Appendix D
Document Revision E
Page 67
13
Drive interface 24V
fuse overload (F3)
14
SCSI Converter SE
term pwr fuse overload
(F1) to drive modules
15
SCSI Converter SE
term pwr fuse overload
(F1) to drive modules
16
SCSI Converter LVD
term pwr fuse overload
(F2) to bus 1 or bus 3
17
SCSI Converter LVD
term pwr fuse overload
(F2) to bus 2
18
Magazine interface
3.3V regulator over-
load (U4)
19
Magazine interface
access door solenoid
24V fuse overload (F2)
20
Magazine interface flip-
per 24V fuse overload
(F3)
21
Power distribution fuse
1 overload +5V inter-
face CJ7 for Power to
Mag. circuit board
22
Power distribution fuse
2 overload +5V inter-
face CJ7 for Power to
RMI circuit board
23
Power distribution fuse
3 overload +24V inter-
face CJ7 for Power to
Mag. circuit board
24
Power distribution fuse
4 overload +24V inter-
face CJ7 for Cabinet
cooling fans
14
1
Circuit board fail
Comm error with VP
decoder circuit board
Error
Code
(hex)
Sub-
code
Error
Description
Subcode
Description
Compo-
nent
Corrective Action
