Plasmon LIBRARIES D2175 User Manual
Page 68
Appendix D
Plasmon D875 - D2175 User Manual
Page 66
Document Revision E
13
1
Fuse overload
Main controller fuse 1
overload +24V interface
CJ3 to CAN bus
2
Main controller fuse 2
overload +5v interface
CJ3 to CAN bus
3
Main controller fuse 3
overload +24V interface
CJ4 to pivot, lift, MTE
4
Main controller fuse 4
overload +5V interface
CJ4 to pivot, lift, MTE
5
Main controller fuse 5
overload +5V interface
CJ5 to VP decoder
6
Main controller fuse 6
overload +5V interface
CJ8 to MC SCSI
adapter
7
Main controller fuse 7
overload +12V interface
CJ8 to MC SCSI
adapter
8
Main controller fuse 9
overload +5V interface
CJ12 to External SCSI
interface circuit board
9
Main controller fuse 10
overload +24V for lift
motor, & interface CJ4
to pivot & lift circuit
board's
10
Main controller fuse 11
overload +24V for step-
per motors, & interface
CJ4 to pivot, lift, MTE
11
Drive interface 3V regu-
lator overload (U14)
12
Drive interface 12V
fuse overload (F2)
Error
Code
(hex)
Sub-
code
Error
Description
Subcode
Description
Compo-
nent
Corrective Action
