• Insert the input module suitable for the input signal specifications.
• Use the SYSTEM SELECTOR button to toggle the systems of the input module that supports two types of
signal specifications. Upon toggling, the input signals are displayed on the screen and cleared automatically.
SD signal SD signal output
(active through)
Serial digital input module (optional)
ET-MD95SD1 (for 480i/576i)
IN OUT
Business digital
video deck
480i Module
ET-MD95SD1
SERIAL
Connecting the signal to the serial digital signal input module
Installation of input module (optional)
