1. Introduction and Installation
13 For assistance, please visit http://www.panasonic.com/consumersupport
1.5 Overview
1.5.1 Base unit
1.5.2 Handset
Removing the shipping tape
Open the front cover by pulling up the center part
(
1), then remove the shipping tape (2).
1 Antennas
2 Document guides
3 Paper tray
4 Metal recording paper guide
5 Recording paper entrance
6 Recording paper exit
7 Tension plate
8 Front cover
9 Document entrance
j Document exit
k Speaker
l Green button (Back cover release button)
m Back cover
5
9 j 8 l m
3 4 7 6
k
2 1
1 Ringer/Message alert indicator
2 Antenna
3 Receiver
4 Headset jack
5 Microphone
6 Speaker
6
1
2
3
4
5
1
2
