Technical Information
VS17SXAD/VS17SXAD-TR
Specification
Color TFT AMLCD flat-panel unit
17-inch SXGA (1280 x 1024)
Control Functions Power
Software Power switch with LED indicator (Press to turn OFF, over 1 (one) sec. to turn ON)
Onscreen display (OSD)
Main Menu
Submenu
Monitor-Control
Auto-Adjust/H-Position/V-Position/Phase/Clock/ Reset/(Graph/Text)/
Port-Select
/
Exit
OSD-Control
OSD-H-Position/OSD-V-Position/OSD Timer/Exit
Graphic-Control
Contrast
/
Brightness
/Color/RGB/Auto-Level/
Reset
/
Exit
MISC-Control
Language/Audio Volume/Information/Exit
Exit
Display area (mm)
337.92 (W) x 270.34 (H), 17-inch diagonal
Response (Rise/Fall) Time
15+10=25 ms typical; 30+25=55 ms maximum (at 25 °C)
Contrast ratio
500:1 typical, 350:1 minimum
Brightness
Non-touch: 250 cd/m
2
typical, 200 cd/m
2
minimum; resistive touch: 200 cd/m
2
typical, 160 cd/m
2
minimum
Viewing angle (degrees)
±85 horizontal and vertical
Pixel pitch (mm)
0.264 (H) x 0.264 (W)
Display color
16M colors
Video interface
Analog and digital
Scanning frequency
24–80 kHz, horizontal; 55–75 Hz, vertical
Number of factory, preset mode
22
Power management
Meets VESA DPMS proposal
Power consumption (ON/OFF)
60/6.0 Watts max
Dimensions W x H x D (mm)
404 x 401 x 234
Weight
4.8 kg with VESA plate, 8.8 kg with desk stand
Power adapter, Ault
12 volts, 6.67 amps, 80 watts
Options
VESA-compatible mounting plate, desk stand, touch screen
Environment
Operating Temperature: 0 (zero) to 40 °C; Relative Humidity: 10% to 90%, noncondensing
Audio
Two 2-Watt per channel speakers with amplifier
Regulatory
See
Only items appearing on the menu when the display is in digital mode
