Unpack the Display
Make sure you receive the following items. If any item is missing or damaged,
see your dealer immediately.
• LCD screen
• Desk stand or VESA mounting plate
• Integrated VGA-VGA-audio cable
• Integrated DVI-DVI-audio cable
• Serial cables (VS17SXAD-TR only)
• AC power adapter with 1.5-meter (5-foot) cable
• Medical-grade power cord (U.S. or European)
• Documentation package, including EU Declaration of Conformity,
quick setup guide, and CD with touchscreen driver and PDF file of
this manual
Selecting a workspace
Before you unpack the VS17 display,
select a suitable workspace for the
display and computer. You need a
stable, level, and clean surface near a
wall outlet.
Even though this display uses little
power, place it in a location that
allows sufficient airflow to ensure
proper ventilation.
Avoid setting up the display near
a window where sunlight often
comes in. You will have difficulty
seeing the screen with glare
reflecting off the display.
