Panasonic 150P User Manual
Page 110

Document Scanner
110
NOTE
Scan
Zoom In
Zoom Out
Adjust parameters for an optimum scanning image, with the view on preview image.
Preview scanning can be repeated any number of times.
Image scanning is only possible by the PC that the device is connected to directly
through the parallel port.
5
Apply the following adjustment on the preview
image:
Drag the scanning frame (black frame) on the
preview window to specify the scanning area. If
an area has already been selected, double-clicking
with Shift button held down selects the whole image.
Clicking / button zooms
in/out a preview-scan image.
Adjust the threshold value, brightness, and contrast
(difference between dark and light portions) as
required.
6
Click the button to import an image into
document desktop.
