WAN Serial Port Configuration 45
Models 2603, 2621, and 2635 User Manual 5 • Serial Port Configuration
WAN Serial Port Configuration
The OnSite Series routers use a sync.-serial interface (X.21, V.35) or a T1/E1 interface for connection to stan-
dard WAN services. Below are the configuration options for the WAN interface.
Serial Interface
The serial interface configuration menus allow the user to configure the serial interface for HDLC based con-
nections.
Variables
The following table lists variables that are configurable on the OnSite’s software:
Variable Options Function
Clock Mode Internal The clock setting for the serial interface will determine the
source of timing for the serial interface only.
External
RX Clock Invert /
TX Clock Invert Inverted The clock invert functions could be used to invert the clocks
that are used on the serial interface. It is not recommended to
change this parameter unless requested by Patton Electron-
ics’ technical support. Keep at default.
Normal
Serial Speed Any n x 64 kbps speed.
Speed should be enter-
ed as the rate, i.e. 512
for 512 kbps or 2048
for 2.048 Mbps Defines the generated speed for internal clock mode opera-
tion or the clock that will be received in external clock mode
operation.
TX Data Sample-
Point Ext Clk When the unit is running in internal clock mode, the setting of
TX Data SamplePoint will indicate to the system which clock
to use to sample the in coming data. Some systems require
that the data be sampled on one clock or another. This is
also useful when tail circuits are being created.
When running in the external clock mode this should be set to
Ext Clk.
Tx Clk
