4.3 Installation Settings

Select in

by using CH+/–, press OK, you will see
the sub-menu as shown in the following figure. It has four items: Satellite
Search, Transponder Search, Satellite Setting and Transponder Setting.

Satellite Search
Select by using CH+/–. Press OK to view the sub-menu as
shown in the following figure.

A. Sat name
Select , then press VOL+. Select satellite by using CH+/– or
PGUP/PGDW.

Press OK to confirm it.

B. Transponder
Select a valid transponder in the satellite to check the signal. Select
, then press VOL+. Select transponder by using CH+/– or
PGUP/PGDW

. Press OK to confirm it.

C. LNB frequency
You can select the predefined LNB frequency by using VOL+/– . Manually
enter a specific frequency in MHz unit by pressing numeric keys.
