LED Display & Button
LED Indicators Descriptions
PWR Power is supplied to the VoIP router
SYS System LED will be ON when the registration toward the GK/SIP proxy is
successful
WAN Orange: the VoIP router is connected to WAN at 10Mb/s.
Green: the VoIP router is connected to WAN at 100Mb/s.
LAN 1 ~ LAN 4 Orange: the VoIP router is connected to LAN at 10Mb/s.
Green: the VoIP router is connected to LAN at 100Mb/s.
Phone 1 ~ Phone 2 Off: the line is idle.
On: the line is being used.
Back Panels Descriptions
DC12V Power Adapter connecter
Reset Reset to the default setting
Phone 1~ Phone 2 Connect to the RJ-11 phone line
LAN 1 ~ LAN 4 10/100Mbps Ethernet port, used to connect PC or NB
WAN 10/100Mbps Ethernet port, used to connect ADSL or cable modem
Press RESET button on rear panel over 8 seconds or until
SYS LED begins to flash, the VoIP Router to this default
LAN/WAN IP address and Username/Passowrd function.
Í
Note
When factory reset is completed, the Default LAN IP is
http://192.168.0.1 from factory.
