Planet Technology VIP-280 - Manual (Page 38)

Supposing you have one VIP-280 connects to four telephones, just pick up phone 1 and dial ‘202’,
phone 2 should rings.
202 VIP-280 local port #2
)))
Line number: 202 Line number: 201
Peer-to-Peer (P2P) mode
38
VIP-280
WAN IP Address: 172.16.0.1
Number: 7001
H.323 IP Phone
IP Address: 172.16.0.100
Number: 1001
SIP IP Phone
IP Address: 172.16.0.200
Number: 2001
VIP-280 configurations:
STEP 1:
Please log in machine via web browser, and select Line Setting in the Line config menu. In
this Line Setting page, please insert the telephone number assigned to this line, and then
the sample configuration screen is shown below (in this sample, we’re using number 7001
for incoming calls).
