Voice communication via SIP proxy server –SIP50
Registration /
Authentication
Registration /
40
Machine configurations on the VIP-280:
STEP 1:
Please log in machine via web browser, and select Register Server setting in the VoIP
Config menu. In this setting page, please insert the account/password information, and then
the sample configuration screen is shown below (in this sample, we’re using the SIP-50 as
the registration server).
ID1: 280 is the phone number that will register to the SIP-50
ID2: vip280 is the name registered in SIP-50
ID3: the password for account vip280
SIP-50 IP Address: 172.16.0.50
Authentication
VIP-280 IP Address: 172.16.0.28
Line Number: 280
VIP-320 IP Address: 172.16.0.32
Line Number: 320
When voice communication is established via “Gatekeeper”,
please add a ”h323:” in front of the IP address.
Such as: the GK IP address is 192.168.0.100, then input
“h323:192.168.0.100” in the IP address.
When voice communication via the SIP proxy server, please
add a “sip:” in front of the IP address/URL.
Such as: the SIP-50 IP address is 192.168.0.50, then input
“sip:192.168.0.50” in the IP address.
L
Hint
