Register Server
If this VoIP router want to use GK/SIP proxy service to transfer the VoIP call, you can input the GK /SIP
information here. The VoIP router can register to up to four GK/SIP proxy simultaneously.
Parameter Description
Register Server Status
Success: Register successful.
Failure: Register failure.
Disable: disable register this GK/SIP proxy server
MAC Display the MAC address of WAN on this VoIP router
SR1~SR4
Enable: Enable the VoIP router to register Server #1.
Disable: Disable the VoIP router to register Server #1.
Remark
For Notify remark for this GK/SIP proxy server. Please use UNDERLINE
to replace the SPACE due to HTTP protocol limitation.
Proxy
Click to enable using GK/SIP proxy function. When enable, VoIP call will
go through the GK/SIP proxy service. Please click here if your VoIP
router is installed behind NAT or firewall without real IP. If you want use
this function, please make sure your GK/SIP proxy has support the
proxy function.
IP address:
Define the GK/SIP proxy server IP, user can input below format
IP address/URL for Gatekeepter server:
such as: h323:172.16.0.100/ h323:h323.testcall.com.tw
IP address/URL for SIP proxy server :
such as: sip:172.16.0.200/sip:sip.testcall.com.tw
Prefix
Specific the prefix number of this VoIP router service for register to
GK/SIP proxy server.
ID1~ID4
Specific the ID of this VoIP router for register to GK/SIP proxy server
H.323: register above ID as H.323 ID.
E.164: register above ID as E.164 ID.
User Name: register above ID as user name for GK/SIP proxy server.
Password: register above ID as password for GK/SIP proxy server.
There are four fields for user define the ID parameters, please reference
the ID1 setting above.
*1:SIP OutboundProxy
To make a call using SIP protocol with proxy server, input the server IP
or domain name in the *1:SIP OutboundProxy field.
