P R I N T E R C O N F I G U R A T I O N
57
Stop Bits Stop Bits
1
Possible Values: 1*, 2
This item sets the number of stop bits to be used at the end of the serial
character frame. This must be set to match the stop bit setting on the host
computer.
Parity Parity
None
Possible Values: None*, Even, Odd
This item selects the parity checking requirements for the serial data bits.
This must be set to match the parity setting on the host computer.
Busy Signal Polarity Busy Polarity
Low
Possible Values: Low*, High
This item selects the polarity of the busy signal (pin 11 of the RS-232C
interface). Busy is set whenever the printer is offline; the serial input buffer
is full.
Data Terminal Ready DTR
Power On/Off
Possible Values: Power On/Off*
Online/Offline
Busy/Not Busy
Selects the condition to be reflected by the DTR signal (pin 20 of the RS-
232C interface). In most cases, especially those involving a MODEM, this
signal should be set to indicate Power On/Off. Selecting
