background image

25

APPENDIX D

DISTANCE CHART, BASED ON 24 AWG (0.5 MM)

Note

DS = downstream from L unit to R unit

US = upstream from R unit to L unit

Symm Line Rate

Distance in feet (km)

6.25 Mbps

4,500 (1.37)

9.38 Mbps

4,150 (1.26)

*

12.5 Mbps

*. This is the only option available for Model

2158A.

4,000 (1.22)

16.67 Mbps

3,300 (1.00)

Asymm Line Rate (DS/US)

Distance in feet (km)

4.17 Mbps/1.56 Mbps (Mode 0)

6,000 (1.83)

9.38 Mbps/1.56 Mbps

5,500 (1.68)

16.67 Mbps/2.34 Mbps

5,000 (1.52)
