background image

22

APPENDIX B

MODEL 2168A AND 2158A SERIES FACTORY

REPLACEMENT PARTS AND ACCESSORIES

Patton Model #

Description

Base Models

2158A/E-2PK

CopperLink 12.5 Mbps Ethernet Extender Kit

(1 Local Unit and 1 Remote Unit); No power supply

2158A/EUI-2PK

CopperLink 12.5 Mbps Ethernet Extender Kit

(1 Local Unit and 1 Remote Unit); 100-240VAC

2158A/L/E

12.5 Mbps CopperLink Ethernet Extender (Local);

RJ45 line; No Power Supply

2158A/L/EUI

12.5 Mbps CopperLink Ethernet Extender (Local);

RJ45 line; 100-240VAC

2158A/R/E

12.5 Mbps CopperLink Ethernet Extender (Remote);
RJ45 line; No Power Supply

2158A/R/EUI

12.5 Mbps CopperLink Ethernet Extender (Remote);
RJ45 line; No Power Supply

2168A/E-2PK

CopperLink Multi Rate 16 Mbps Ethernet Extender Kit

(1 Local Unit and 1 Remote Unit); No power supply

2168A/EUI-2PK

CopperLink Multi Rate 16 Mbps Ethernet Extender Kit

(1 Local Unit and 1 Remote Unit);RJ45 Connectors only;
100-240VAC

2168A/L/E

16 Mbps Ethernet Extender Kit (Local); RJ45 line;

No Power Supply

2168A/L/EUI

16 Mbps Ethernet Extender Kit (Local); RJ45 line;

100-240VAC

2168A/L/TB45/E

16 Mbps Ethernet Extender Kit (Local);

Terminal Block and RJ45 line; No Power Supply

2168A/L/TB45/EUI

16 Mbps Ethernet Extender Kit (Local);

Terminal Block and RJ45 line; 100-240VAC

2168A/R/E

16 Mbps Ethernet Extender Kit (Remote); RJ45 line;

No Power Supply

2168A/R/EUI

16 Mbps Ethernet Extender Kit (Remote); RJ45 line;

100-240VAC

2168A/R/TB45/E

16 Mbps Ethernet Extender Kit (Remote);

Terminal Block and RJ45 line; No Power Supply

2168A/R/TB45/EUI

16 Mbps Ethernet Extender Kit (Remote);

Terminal Block and RJ45 line; 100-240VAC

2168A/TB45/E-2PK

CopperLink Multi Rate 16 Mbps Ethernet Extender Kit

(1 Local Unit and 1 Remote Unit);

Terminal Block Line side; No power supply

2168A/TB45/EUI-2PK

CopperLink Multi Rate 16 Mbps Ethernet Extender Kit

(1 Local Unit and 1 Remote Unit);

Terminal Block Line side; 100-240VAC

0 7 M 2 1 6 8 A -U M
