ᕤᕢ ᕣ ᕡ – Pelco Dx8000 User Manual
Page 39
C623M-C (3/05)
39
To configure TCP/IP ports and bandwidth throttle:
1. If necessary, enter a new base port number. (9002 is the default)
2. If necessary, enter a new software upgrade port. (9003 is the default)
3. Drag the network bandwidth throttle slider to the desired value. (Client bandwidth can be adjusted from a minimum of 256 Kbps to a
maximum of 10 Mbps in increments of 256 Kbps.)
4. Click Apply.
Figure 31. Base Port and Bandwidth Throttle Setup
NOTE: Consult your network administrator when assigning or changing the port numbers. Make sure that ports are not blocked by a
firewall.
