Cleaning
For fax advantage assistance, call 1-800-435-7329.
Thermal head
Dotted
area
Center
part
Back cover
open lever (green)
Front
cover
Back
cover
Back cover open
button (green)
OR
Black sheets
Thermal head
Thermal head !
If dirty patterns or black or white bands appear on a copied or received document, check
whether there is dust on the thermal head and clean the thermal head to remove the dust.
1 Disconnect the power cord and the
telephone line cord.
2 Open the front cover by pulling up the center
part.
3 Open the back cover by pushing the back
cover open button (green) or pushing the
back cover open lever (green).
4 Clean the thermal head with a cloth
moistened with isopropyl rubbing alcohol,
and let it dry thoroughly.
● Do not touch the black sheets on the
thermal head.
5 Close the back cover securely by pushing
down on the dotted area at both ends. Close
the front cover securely.
6 Connect the power cord and the telephone
line cord.
Caution:
● To prevent a malfunction due to static
electricity, do not use a dry cloth and do not
touch the thermal head directly.
Power cord
Telephone
line cord
