14
Setup (Base Unit)
For fax advantage assistance, call 1-800-435-7329.
Connections !
To the single
telephone line
jack (RJ11C)
To the power
outlet
(120 V, 60 Hz)
Telephone
line cord
Power cord
Power surge
protector ( )
Line surge
protector ( )
1 Connect the telephone line cord.
2 Connect the power cord.
Note:
● The warranty does not cover damage due to power line surges or lightning. For additional equipment
protection, we recommend the use of a surge protector. The following types are available: TELESPIKE
BLOK MODEL TSB (TRIPPE MFG. CO.), SPIKE BLOK MODEL SK6-0 (TRIPPE MFG. CO.), SUPER
MAX (PANAMAX) or MP1 (ITW LINX).
Caution:
● When you operate this product, the power outlet should be near the product and easily
accessible.
To use the fax machine with a computer on the same line
● We recommend you use separate wall jacks for the fax machine and the computer.
● Set the fax machine to TEL mode (p. 46).
● The device which has the shortest ring setting will answer the call first.
● If the computer provides a port for a telephone line, connect the fax machine to this port on the computer.
