CTM-MS4

Page - 5 -

Installation Manual

M5 x 25

(Qty 8)

M6 x 35

(Qty 8)

M5 x 30

(Qty 8)

M8 x 20

(Qty 8)

M6 x 20

(Qty 8)

M8 x 25

(Qty 8)

M6 x 25

(Qty 8)

M8 x 30

(Qty 8)

M6 x 30

(Qty 8)

M8 x 35

(Qty 8)

M8 x 70

(Qty 4)


Nylon spacers and flat washers’ actual size
NOTE:

The nylon spacers may be stacked to achieve proper spacing.

¼” Nylon

Spacers

(Qty 8)

¼” Nylon

Spacers

(Qty 8)

½” Nylon

Spacers

(Qty

12)

9/16” Nylon

Spacers

(Qty 8)

5/16” Flat

Washers

(Qty 8)

Nylon Sleeves

(Qty 8)

1” Nylon Spacers

(Qty 8)
