CTM-MS4

Installation Manual

Page - 4 -

Parts List

NOTE:

This wall mount is shipped with all proper installation hardware and components. Make sure that
none of these parts are missing and/or damaged before beginning installation. If there are parts
missing and/or damaged, please stop the installation and contact Premier Mounts

(800-368-9700).

Wall Plate
(Qty 2)

Mounting Brackets
(Qty 2)

5/16” Flat
Washers
(Qty 12)

5/16” x 3” Lag Bolts
(wooden studs only)
(Qty 12)

M6 x 30mm
Lateral Shift
Locking
Screws (Qty 2)

Griplate™ (Qty 8)

M6 x 12mm
Safety Knobs
(Qty 2)

M8 Hex Nut
(

Qty

2)

M8 x 16mm
Hex Head
Bolt (

Qty

2)

5/16” x 1-1/4”
Mounting Rod
Set Screw (

Qty 1)

Installation Tools

Phillips Head Screw Driver

Soft Material/ Blanket

½ ” Socket and Wrench

Pencil

Tape Measure

Drill Gun

Level (Supplied)

Thread Depth Indicator (Supplied)
