CTM-MS4

Page - 14 -

Installation Manual

Installing the Flat Panel Display (CTM-MS4)

WARNING:

AT LEAST TWO QUALIFIED PERSONNEL ARE STRONGLY RECOMMENDED FOR
INSTALLATION OF THIS PRODUCT. FAILURE TO DO SO COULD RESULT IN
SERIOUS INJURY AND POSSIBLE DAMAGE TO THE FLAT PANEL.


1.

Raise the flat panel with the mounting brackets secured to the flat panel and insert the top hooks over the

upper rod. The lower hooks should rest on the lower rod (Figure 17).

Figure 17

Top

Wall Plate

Bottom
