Arts – Life Fitness G3 User Manual
Page 6
5
P
ARTS
L
IST
NOTE: Some of the components may be pre-assembled.
1
FRONT BASE
1
2
UPRIGHT
1
3
BASE CONNECTOR
1
4
REAR BASE
1
5
RIGHT ARM
1
6
LEFT ARM
1
7
SEAT ADJUST
1
8
LEG PEDESTAL
1
9
BACK PAD
1
10
PULLEY PLATE
2
11
BASE PLATE
2
12
C-RING
2
13
BOOM PULLEY PLATE
2
14
RIGHT BOOM PLATE
1
15
LEFT BOOM PLATE
1
16
SEAT PAD
1
17
ROLLER PAD
6
18
76" GUIDE ROD
2
19
ADJUST. SEWN HANDLE
2
20
SHORT SEWN HANDLE
2
21
WEIGHT PLATE
15
22
LOW ROW BAR
1
23
HEAD PLATE ASSY
1
24
3/4 X 18" TUBE
1
25
3/4 X 18-3/8" TUBE
1
26
3/4 X 21" TUBE
1
27
WEIGHT STACK PIN
1
28
WEIGHT STACK CUSHION
2
29
102 3/4” WEIGHT STACK CABLE
1
30
163 1/8” LEG CABLE
1
31
215 1/16” ARM CABLE
1
32
181” BOOM CABLE
1
33
WEIGHT STACK SPACER
2
34
3-1/2" CABLE GUARD
1
35
4-1/2" CABLE GUARD
1
36
SHAFT COLLAR
2
37
3-1/2" PULLEY
18
38
4-1/2" PULLEY
3
39
QUICK CONNECT
4
40
T-HANDLE SPRING PIN
1
41
SNAP LINK
4
42
GUIDE BRACKET
2
43
5-PRONG KNOB
1
44
ROLLER PAD CAP
6
45
PLASTIC WASHER
12
46
1/2" RH WASHER
2
47
RH CAP
2
48
3/8 X 3/4" FLANGE SPACER
2
49
3/8 X 1-1/16" FLANGE SPACER
2
50
ACCESSORY RING
4
51
3/8" X 1" SPACER
9
52
WEIGHT STACK LABEL
1
53
3/8 X 1-3/4" BOLT
10
54
5/16 x 1" BUTTON HEAD
6
55
3/8 X 2" BOLT
2
57
3/8 X 3-3/4" BOLT
17
58
1/2 X 104mm BOLT
1
59
12 LINK CHAIN
1
60
3/8 X 2-3/4" BOLT
2
61
1/2 X 5-3/4" BOLT
1
62
1/2" LOW HEIGHT LOCK NUT
2
63
3/8" SILVER LOCK NUT
35
64
3/8" FLAT WASHER
24
65
61” FRONT GUIDE CABLE
2
66
FOOT PLATE
1
67
3/8 X 3" SILVER BOLT
2
68
3/8 X 4-1/4" SILVER BOLT
6
70
3/8 X 1-1/4" BOLT
2
71
BACK PAD ADJUSTMENT
1
72
SWIVEL PULLEY ASSEMBLY
2
73
ANKLE STRAP
1
74
71.5” REAR GUIDE CABLE
2
75
ACCESSORY ADAPTER BAR
1
76
ACCESSORY LAT BAR
1
77
3/8 X 3" BLACK BOLT
2
78
3/8” BLACK LOCK NUT
2
79
EXERCISE CARD
1
80
TOUCH-UP PAINT (Platinum)
1
81
TOUCH-UP PAINT (Shadow Gray)
1
82
SILICON
1
Key Description
Qty Key Description
Qty
