56
Chapter 5: Configuring the Switch through the Web Utility
Security
24-Port 10/100 + 2-Port Gigabit Switch with Webview and Power over Ethernet
Security
The Security tab includes links to the following screens.
• ACL Conf.
• ACL Port Binding
• 802.1xUsers
• 802.1xPort Conf.
• Radius Server
• Port Security
• Storm Control
• HTTPS Settings
• System Password
ACL Conf.
Access Control Lists (ACL) provide packet filtering for IP frames (based on address, protocol, Layer 4 protocol port
number or TCP control code) or any frames (based on MAC address or Ethernet type). To filter incoming packets,
first create an access list, add the required rules, specify a mask to modify the precedence in which the rules are
checked, and then bind the list to a specific port.
Enter an ACL name in the Name field (with up to 16 characters), select the list type (IP Standard, IP Extended, or
MAC), and click
Add to open the configuration screen for the new list.
Figure 5-39: Security - ACL Conf
