Linksys SRW224P User Manual
Page 25
17
Chapter 4: Configuration using the Console Interface
Configuring the Switch through the Console Interface
24-Port 10/100 + 2-Port Gigabit Switch with Webview and Power over Ethernet
SNMP
The SNMP screen allows you to set the Switch’s SNMP settings.
SNMP Server. Enable or Disable the SNMP function for the Switch.
SNMP Port. Set the TCP port that will be used for sending and receiving SNMP packets.
Network Configuration
The Network Configuration Screen allows you to use PING to test network connectivity. Enter the IP address of the
interface or device you wish to PING and select the
Execute action.
Figure 4-17: SNMP
Figure 4-18: Network Configuration/PING
