General, Venting – Lochinvar KNIGHT WH 55 - 399 User Manual
Page 15
15
Installation & Operation Manual
Figure 3-4 PVC/CPVC Two-Pipe
Vertical Termination - See page 27
for more details
Figure 3-5 Stainless Steel Two-
Pipe Vertical Termination - See
page 27 for more details
Figure 3-7 PVC/CPVC Vertical Vent, Sidewall Air
Figure 3-8 Stainless Steel Vertical Vent, Sidewall Air
Direct venting options - Vertical Vent
Direct venting options - Vertical Vent, Sidewall Air
Stainless steel vent/air design and terminations will vary slightly by manufacturer.
NOTICE
Figure 3-6 PVC/CPVC Concentric
Vertical Termination - See page 29
for more details
3
General
venting
(continued)
