2: Overview
XPort AR User Guide 19
Addresses and Port Numbers
Hardware Address
The hardware address is also referred to as the Ethernet address or MAC address. The first three
bytes of the Ethernet address are fixed and read 00-20-4A, identifying the unit as a Lantronix
product. The fourth, fifth, and sixth bytes are unique numbers assigned to each unit. The following
sample shows a hardware address:
00-20-4A-14-01-18
or
00:20:4A:14:01:18
IP Address
Every device connected to an IP network must have a unique IP address. This address references
the specific unit.
Port Numbers
Every TCP connection and every UDP datagram is defined by a destination and source IP
address, and a destination and source port number. For example, a Telnet server commonly uses
port number 23.
The following is a list of the default server port numbers running on the XPort AR:
 TCP Port 22—SSH Server (Command Mode configuration)
 TCP Port 23—Telnet Server (Command Mode configuration)
 TCP Port 80—HTTP (Web Manager configuration)
 TCP Port 443—HTTPS (Web Manager configuration)
 UDP Port 161—SNMP
 TCP Port 21—FTP
 UDP Port 69—TFTP
 UDP Port 30718—LDP (Lantronix Discovery Protocol) port
 TCP/UDP Port 10001—Tunnel 1
 TCP/UDP Port 10002—Tunnel 2
Product Information Label
Figure 2-1 shows the bottom of each unit which has a product information label. The label
contains the following information:
 Product ID (name)
 Product description
