Chapter 6 Buffer memory
6 - 5
6) Digital output value (Address 08 ~ 11)
- The digital value converted from analog input value is stored at this area.
- If an error occurs, the d igital output value keeps the previous value.
Address Description
08 The digital output value of channel 0
09 The digital output value of channel 1
10 The digital output value of channel 2
11 The digital output value of channel 3
7) Channel status (Address 12)
- Indicates a channel is operating or not by turning on/off the corresponding bit.
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
– – – – – – – – – – – – Ch3 Ch2 Ch1 Ch0
8) Error code (Address 13 ~ 16)
- Shows an error code when an error occurred.
Error code Description
h00 No error
h11 The averaging count setting error
Channel status
0 : Not operating
1 : Operating Ignored
