Chapter 6 Buffer memory
6 - 2
6.1.2 G3F-AD3A / G4F-AD3A
The buffer memory of G3F-AD3A and G4F-AD3A has same configuration.
Address
(decimal)
Name Description
Default
value
Remark
00 Channel enable Enable / disable channel operation h00 R / W
01
Input voltage / current
type Assign the type of analog input
voltage / current
h00 R / W
02
Average count
processing enable Enable / disable average count processing
per each channel
h00 R / W
03 Avg. count of Ch0 Assign the count of Avg. processing of Ch0 h02 R / W
04 Avg. count of Ch1 Assign the count of Avg. processing of Ch1 h02 R / W
05 Avg. count of Ch2 Assign the count of Avg. processing of Ch2 h02 R / W
06 Avg. count of Ch3 Assign the count of Avg. processing of Ch3 h02 R / W
07 Avg. count of Ch4 Assign the count of Avg. processing of Ch4 h02 R / W
08 Avg. count of Ch5 Assign the count of Avg. processing of Ch5 h02 R / W
09 Avg. count of Ch6 Assign the count of Avg. processing of Ch6 h02 R / W
10 Avg. count of Ch7 Assign the count of Avg. processing of Ch7 h02 R / W
11 Data enable Make enable the new setting of buffer 0~10 h00 R / W
12 Ch0 digital output value Digital output value of channel 0 - R
13 Ch1 digital output value Digital output value of channel 1 - R
14 Ch2 digital output value Digital output value of channel 2 - R
15 Ch3 digital output value Digital output value of channel 3 - R
16 Ch4 digital output value Digital output value of channel 4 - R
17 Ch5 digital output value Digital output value of channel 5 - R
18 Ch6 digital output value Digital output value of channel 6 - R
19 Ch7 digital output value Digital output value of channel 7 - R
20 Channel status Indicate run/stop of each channel - R
21 Ch0 error code
Shows error code when an error occurred
on channel 0
- R
22 Ch1 error code
Shows error code when an error occurred
on channel 1
- R
23 Ch2 error code
Shows error code when an error occurred
on channel 2
- R
24 Ch3 error code
Shows error code when an error occurred
on channel 3
- R
25 Ch4 error code
Shows error code when an error occurred
on channel 4
- R
26 Ch5 error code
Shows error code when an error occurred
on channel 5
- R
27 Ch6 error code
Shows error code when an error occurred
on channel 6
- R
28 Ch7 error code
Shows error code when an error occurred
on channel 7
- R
* All 16-bit data
