LEICA ASP300 - Manual (Page 55)

55 Leica ASP300
→ →
↓
↓
Printing run logs
Printing is possible when the PRINT symbol is displayed.
For the PRINT symbol to be displayed, a printer must have been
configured for the instrument.
The following lists and protocols can be printed:
•
reagent list,
• stations list,
• reagent status list,
• all programs,
• run log,
• error log.
5.7 Configuring a printer (optional)
To select and configure a printer, proceed as follows:
• With a Centronics standard cable, connect the printer to
the printer port (refer
chapter 4.4 , Fig. 6 ).
5. Operation
