ELECTRICAL DIAGRAMS
G-5
COMMANDER 500
PC BOARD ASSEMBLY - BATTERY PC BOARD
SO
LID EDGE
EN-
16
8
MANUFACTURING TOLERANCE PER E2056
UNLESS OTHERWISE SPECIFIED TOLERANCE
SCALE:
DO NOT SCALE THIS DRAWING
ON 3 PLACE DECIMALS IS ± .002
THIS SHEET CONTAINS PROPRIETARY INFORMATION OWNED BY THE LINCOLN ELECTRIC COMPANY AND IS NOT TO BE REPRODUCED, DISCLOSED OR USED WITHOUT THE EXPRESS WRITTEN PERMISSION OF THE LINCOLN ELECTRIC COMPANY, CLEVELAND, OHIO U.S.A.
DESIGN INFORMATION
t
DRAWN BY:
WITH PUBLISHED STANDARDS.
DATE:
ON 2 PLACE DECIMALS IS ± .02
MATERIAL TOLERANCE (" ") TO AGREE
ON ALL ANGLES IS ± .5 OF A DEGREE
SUBJECT:
Chg. Sheet No.
ENGINEER:
EQUIPMENT TYPE:
DRAWING No.:
MAP
MISC.
BATTERY PC BD. ASSEMBLY
L
1:1
5-26-99
REFERENCE:
SUPERSEDING:
APPROVED:
"X" INFO.
5000736
XF-UF
11325-1
3-31-2000
BA
TT
ERY
L113
25-1
R
36
R3
5
R
44
R
45
MOV1
D
1
D2
D
3
D9
D12
D1
0
Q
7
Q1
Q2
Q3
Q5
Q4
Q
6
Q
8
Q9
D4
D5
D6
D7
D
8
D
14
D13
D15
D16
C
6
C
1
C
2
J4
3
R2
6
R2
0
R2
1
R1
5
R2
8
R1
R3
2
R3
3
R3
4
R2
7
R
18
R1
9
R2
5
R5
R1
1
R1
2
R13
R14
R16
R17
R2
9
R6
R
7
R8
R9
R1
0
R
2
R3
R4
R
38
R
39
R
40
R46
R47
R48
R49
R3
7
R30
C7
C8
C9
C10
C
11
C1
2
C3
X
1
X
2
X
3
C
4
C5
D1
7
BUY PER E3867
TEST PER E3868-1
UNLESS OTHERWISE SPECIFIED:
CAPACITORS = MFD/VOLTS
RESISTORS = 1/4W/OHMS
INDUCTANCE = HENRYS
SCHEMATIC REFERENCE - L11309
BUY AS
IDENTIFICATION CODE
L11325-1C1
}
{
NOTES:
N.A.
CAUTION:
THIS DEVICE IS SUBJECT TO DAMAGE BY
STATIC ELECTRICITY. LINCOLN ELECTRIC TO SEE E2454
BEFORE HANDLING.
N.C.
SECURE PC BOARD ASSEMBLY IN PLACE WITH ITEM (3).
(2 PLACES)
N.D.
IDENTIFY COMPLETE ASSEMBLY WITH A PRINTED LABEL OR
OTHER PERMANENT MARKING IN AREA SHOWN.
N.E.
NO COMPONENTS ON BOTTOM SIDE OF PC BOARD.
V
ITEM
PART NO.
QTY
PC BOARD REFERENCE
DESIGNATORS
DESCRIPTION
1
L11325-C
1
BATTERY PC BOARD BLANK
2
M19436-3
1
POTTING TRAY
3
S8025-80
2
SELF TAPPING SCREW
4
E2527
112 g
EPOXY ENCAPSULATION RESIN
5
E3539
AS REQ'D
ELECTRICAL INSULATING COMPOUND
6
T11577-26
2
C1, C2
CAPACITOR; PEF; 0.1/100V; 10%
7
S16668-8
1
C3
CAPACITOR; CEMO; 330pf / 100V; 5%
8
S13490-121
1
C4
CAPACITOR; ALEL; 1000/35V +30% / -20%
9
S13490-15
1
C5
CAPACITOR; ALEL; 100/16V +75% / -10%
10
T11577-58
1
C6
CAPACITOR; CD; 0.0047/3000V; 20%
11
S16668-11
6
C7 THRU C12
CAPACITOR; CEMO;.1 / 50V; 10%
12
T12705-37
3
D1, D2, D3
DIODE; AXLDS; 3A; 40V; SCHOTTKY
13
T12199-1
9
D4, D5, D6, D7, D8, D13, D14, D15, D16 DIODE; AXLDS; 1A; 400V; 1N4004
14
T12705-29
4
D9, D10, D12, D17
DIODE; AXLDS; 3A; 600V; 1N5406
15
S24020-16
1
J43
CONNECTOR; MOLEX; MINI; PCB; 16 PIN; TIN
16
T13640-26
1
MOV1
MOV; 14VRMS; 100J; 20MM
17
T12704-68
6
Q1 THRU Q6
TRANSISTOR; NPN;TO226; 0.5A; 40V; 2N4401
18
T12704-69
1
Q7
TRANSISTOR; PNP;TO226; 0.5A; 40V; 2N4403
19
T12704-49
1
Q8
TRANSISTOR; P; T220; 8A; 150V; MJE15031
20
T12704-41
1
Q9
TRANSISTOR; N; T220; 8A; 150V; MJE15030
21
S19400-4750
1
R1
RESISTOR; MF; 1/4W; 475 OHM; 1%
22
S19400-1001
2
R2, R4
RESISTOR; MF; 1/4W; 1K OHM; 1%
23
S19400-2211
2
R3, R25
RESISTOR; MF; 1/4W; 2.21K OHM; 1%
24
S19400-4751
1
R6
RESISTOR; MF; 1/4W; 4.75K OHM; 1%
25
S19400-1002
4
R7, R8, R9, R10
RESISTOR; MF; 1/4W; 10K OHM; 1%
26
S19400-1211
6
R11, R12, R13, R14 & R16, R17
RESISTOR; MF; 1/4W; 1.21K OHM; 1%
27
S19400-6812
1
R15
RESISTOR; MF; 1/4W; 68.1K OHM; 1%
28
S19400-3321
2
R18, R19
RESISTOR; MF; 1/4W; 3.32K OHM; 1%
29
S19400-8251
2
R20, R21
RESISTOR; MF; 1/4W; 8.25K OHM; 1%
30
S19400-9091
1
R26
RESISTOR; MF; 1/4W; 9.09K OHM; 1%
31
S19400-3322
2
R5, R27
RESISTOR; MF; 1/4W; 33.2K OHM; 1%
32
S19400-5110
1
R28
RESISTOR; MF; 1/4W; 511 OHM; 1%
33
S19400-1003
1
R29
RESISTOR; MF; 1/4W; 100K OHM; 1%
34
S18380-3
1
R30
THERMISTOR; PTC; .08-0.19 OHMS; 1.85A
35
S19400-3921
3
R32, R33, R34
RESISTOR; MF; 1/4W; 3.92K OHM; 1%
36
T14649-1
2
R35, R36
RESISTOR; WW; 10W; 4.7 OHM; 5% SQ.
37
S19400-47R5
1
R37
RESISTOR; MF; 1/4W; 47.5 OHM; 1%
38
S19400-24R9
1
R38
RESISTOR; MF; 1/4W; 24.9 OHM; 1%
39
S19400-1000
6
R39, R40, & R46, R47, R48, R49
RESISTOR; MF; 1/4W; 100 OHM; 1%
40
T14648-22
2
R44, R45
RESISTOR; WW; 5W; 50 OHM; 5% SQ.
41
S15128-11
1
X1
IC; COMPARATOR; QUAD; 2901N
FOR ITEMS LISTED BELOW REFER TO ELECTRONIC COMPONENT DATABASE FOR COMPONENT SPECIFICATIONS
2
1
3
N.E.
N.D.
G-5
