Table 27, Sitenet multiport4 intellislot pin assignment – Liebert Emerson NX UPS System User Manual
Page 78
Options—For Assembly Inside the UPS Cabinet
70
Figure 41 SiteNet MultiPort4 Intellislot pin configuration
Table 27
SiteNet MultiPort4 Intellislot pin assignment
Pin
Assignment
Description
1
Low Battery
2
Not Used
3
Not Used
4
Not Used
5
Not Used
6
Not Used
7
Low Battery Common
8
Utility Fail Common
9
Utility Fail
UPS
CPU
CPU
CPU
CPU
