24
Install memory, firmware, or option cards
Installing an option card
Your printer has one expansion card slot that supports a number of option cards. The
following table describes their function.
Note: The network models ship with an
Ethernet print server already installed.
You need a small Phillips screwdriver to install these options.
1 Remove the system board access cover (see page 20).
2 Remove the screw from the metal plate that covers the connector slot, and then
lift the plate off.
Save the screw.
Warning: Option cards are easily
damaged by static electricity. Touch
something metal on the printer before
you touch an option card.
3 Unpack the option card.
Save the packing materials.
4 Align the connector on the option card with the connector on the system board.
The cable connectors on the side of the option card must fit through the
connector slot.
5 Push the option card firmly into the option card connector.
6 Secure the card to the system board with the screw.
Card Function
MarkNet internal print server Adds an Ethernet or Token-Ring port so you can connect your printer to a network.
Parallel 1284-B Interface Card Adds a parallel port.
Serial Interface Card Adds a serial port.
Connectors
