79
Table 5-50. Acceptance Mask Register: ID 12
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OFFSET 54h
FIELD
ID12 ID11 ID10 ID09 ID08 ID07 ID06 ID05 ID04 ID03 ID02 ID01 ID00 IDE RTR
///
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Table 5-51. Acceptance Mask Register: ID12 Definitions
Bits Field Name Description
15:3 ID[28:13] Message Data
2 IDE Extended Identifier Bit
1 RTR Remote Bit
0 /// Reserved
Table 5-52. Acceptance Mask Register: Data 55
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
OFFSET 56h
FIELD
D55 D54 D53 D52 D51 D50 D49 D48 D63 D62 D61 D60 D59 D58 D57 D56
RESET 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Table 5-53. Acceptance Mask Register: Data 55 Definitions
Bits Field Name Description
15:0 D[55:56] Message Data
