Extended Slave Address Register
Table 3-19. Extended Slave Address Register
BIT
7
6
5
4
3
2
1
0
OFFSET
D008
FIELD
SLAX7 SLAX6 SLAX5 SLAX4 SLAX3 SLAX2 SLAX1 SLAX0
RESET
0
0
0
0
0 0 0 0
RW
RW
RW
RW
RW
RW RW RW RW
Table 3-20. Extended Slave Address Register Definitions
Bits
Field Name
Description
7
SLAX7
Extended slave address.
6
SLAX6
Extended slave address.
5
SLAX5
Extended slave address.
4
SLAX4
Extended slave address.
3
SLAX3
Extended slave address.
2
SLAX2
Extended slave address.
1
SLAX1
Extended slave address.
0
SLAX0
Extended slave address.
Software Reset Register
Table 3-21. Software Reset Register
BIT
7
6
5
4
3
2
1
0
OFFSET
D00E
FIELD
HRST ///
RESET
0
0
0
0
0 0 0 0
RW
RW
RW
RW
RW
RW RW RW RW
Table 3-22. Software Reset Register Definitions
Bits
Field Name
Description
7 HRST
Hardware Reset to I
2
C Controller
1 = causes the I
2
C controller to reset the same as a hardware reset. The
hardware reset is self-clearing.
0 = only the I
2
C controller Control register is cleared.
6:0
///
Reserved
