Hex Offset
Register
30
RxMessage: ID, ID28-13
32
ID12-00
34
RxMessage: Data, D55-48, D63-56
36
D39-32, D47-40
38 D23-16,
D31-24
3A
D07-00, D15-08
3C
RxMessage: RTR, IDE, DLC_3-0,AFI_2-0
3E
RxMessage: Control Flags, Fifo_Lvl_2-0, MsgAval
40
Transmitter and Receive Error Counter
42
Error Status
44
Message Level Threshold
46
Interrupts Flags
48
Interrupt Enable Register
4A
CAN mode, Loop_Back, Passive, Run
4C
CAN Bit Rate Div., cfg_bitrate_10-0
4E
CAN tsegs
50
Acceptance Filter Enable Register, AFE_2-0
52
Acceptance Mask Register 0 (AMR0), ID28-13
54
ID12-00, IDE, RTR
56
D55-48, D63-56
58
Acceptance Code Register 0 (ACR0), ID28-13
5A
ID12-00, IDE, RTR
5C D55-48,
D63-56
5E
Acceptance Mask Register 1 (AMR1), ID28-13
60
ID12-00, IDE, RTR
62
D55-48, D63-56
64
Acceptance Code Register 1 (ACR1), ID28-13
66
ID12-00, IDE, RTR
68 D55-48,
D63-56
6A
Acceptance Mask Register 2 (AMR2), ID28-13
6C
ID12-00, IDE, RTR
6E
D55-48, D63-56
70
Acceptance Code Register 2 (ACR2), ID28-13
72
ID12-00, IDE, RTR
74 D55-48,
D63-56
76
Arbitration Lost Capture Register (ALCR)
78
Error Capture Register (ECR)
