Page 32
24
Data Register
The Data register contains the transmission data/slave address or the receipt data byte.
In transmit mode, the byte is sent most-significant bits first.
In receive mode, the first bit received is placed in the register’s most-significant bits.
After each byte transmits, the Data register contains the byte present on the bus; therefore, if
arbitration is lost, the Data register has the correct receive byte.
Table 3-10. Data Register
BIT
7
6
5
4
3
2
1
0
OFFSET
D002
FIELD
Transmission Data/Slave Address or Receipt Data Byte
RESET
0
0
0
0
0 0 0 0
RW
RW
RW
RW
RW
RW RW RW RW
Table 3-11. Data Register Definitions
Bits
Field Name
Description
7:0
SLA6 – SLA0
Transmission Data/Slave Address or Receipt Data Byte
