Chapter 2: Features and Functions
Features and Functions
Rear View of Printer
Part Name
Function
Parallel or serial connector
Connects the parallel or serial cable.
Interface mode switch
Switches to RS-232c or RS-422 mode.
Tear-Off bar
Allows you to tear off continuous forms.
Tractor connector
Supplies power to the optional Tractor 2 Feeder.
Power connector
Connects power from the power cord to the printer.
Power
Connector
Tractor Connector
Interface Mode Switch
Parallel or Serial Connector
Tear-Off Bar
