DEVICE S–1000 CONNECTIONS FACTORY DEFAULT DECODING MODES
Digital Analog Digital Analog
Video Audio Audio Dolby 2.0 Dolby 5.1 DTS 5.1 PCM
DVD Component 1 COAX 1 S1 Dolby D+ Dolby D 5.1 DTS 5.1 Dolby PLII Dolby PLII
Dolby PLII Movie Movie Movie Movie
CABLE HDMI TM 2 COAX 3 S4 Dolby D+ Dolby D 5.1 DTS 5.1 Dolby PLII Dolby PLII
Dolby PLII Movie Movie Movie Movie
SAT HDMI TM 1 OPT 1 S3 Dolby D+ Dolby D 5.1 DTS 5.1 Dolby PLII Dolby PLII
Dolby PLII Movie Movie Movie Movie
VCR S-Video 2 Disabled VCR N/A N/A N/A N/A Dolby PLII
Movie
TV Composite 1 COAX 2 S2 Dolby D+ N/A N/A N/A Dolby PLII
Dolby PLII Movie Movie
CD Disabled Disabled B1 N/A N/A N/A N/A Preamp
TUNER Disabled Disabled S5 N/A N/A N/A N/A Preamp
AUX Disabled Disabled 7.1 N/A N/A N/A N/A N/A
GAME Component 2 OPT 2 S6 N/A Dolby D 5.1 DTS 5.1 Dolby PLII Preamp
TAPE Composite 3 Disabled Tape N/A N/A N/A N/A Preamp
Krell S–1000 15
TABLE 1 S–1000 Connections and Corresponding
Factory Default Decoding Modes, by Device
Connect the S–1000 to the rest of the components in your system,
using this table as a guide.
When the S–1000 is in the operating mode, press the mode button or M1
key (16) on the remote control to read the current processing mode in the
front panel display. Press the mode button or M2 key (17) to review and select
other available modes. See Decoding Modes, on page 9.
In the menu mode, Step 2, Configure Devices screens show available
decoding modes, by device. For example, see Assign Digital Audio
Inputs, on page 34; DTS Control, on page 44; PLII Control, on page 45.
The Appendix: Decoding Modes for the S–1000, on page 60, shows all
the decoding modes for the S–1000, and includes a listing of Krell Music
Surround modes.
Notes
