English | 17
Monitor Unit
Screen size
: 6.95 inches wide
156.2(W) × 82.4(H) × 176.0(Diagonal) mm
6-1/8(W) × 3-1/4(H) inches
Display system
: Transparent TN LCD panel
Drive system
: TFT active matrix system
Number of pixels
: 336,960 pixels (480 H × 234 V × RGB)
Effective pixels
: 99.99%
Pixel arrangement
: RGB striped arrangement
Back lighting
: Cold cathode tube
Speaker power
: 0.5 W (40 × 20 mm)
Hideaway Unit
Colour system
: NTSC/ PAL
Video input level (RCA jacks)
: 1 ± 0.1 Vp-p/ 75 Ω
Audio input level (RCA jacks)
: 1 V/ 55 KΩ
Video output level (RCA jacks)
: 1 ± 0.1 Vp-p/ 75 Ω
Audio output level (RCA jacks)
: 1 V/ 1 KΩ
Analog RGB input (13P)
: 0.7 Vp-p/ 75 Ω
Specifications subject to change without notice.
General
Operating voltage
: 14.4 V DC (11 - 16 V)
Consumed Power
: 14 W
Current consumption
: 1.5 A
Operational temperature range
: –10°C to +60°C
Storage temperature range
: –30°C to +85°C
Dimensions (W × H × D)
Monitor unit : 177 Ч 121.5 Ч 34 mm
7 Ч 4-6/8 Ч 1-5/16 inch
Hideaway unit : 143 Ч 37 Ч 99 mm
5-5/8 Ч 1-7/16 Ч 4-7/8 inch
Weight
Monitor unit : 460 g (1.01 lbs)
Hideaway unit : 390 g (0.86 lbs)
Specifications
Although the effective pixels for the liquid crystal panel is given as 99.99% or more, 0.01% of pixels may not light or may
light incorrectly.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause
harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the
authority to operate this equipment if an unauthorized change or modification is made.
NOTE
This Class B digital apparatus complies with Canadian ICES-003.
