PARTS LIST
MODEL NO.: CH0030SQB
CH0036SQB
CH0042SQB
CH0048SQB
(Optional Duct Cover)
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Ducting Transition B001-2
CH0030SQB 10-2130
CH0036SQB 10-2136
CH0042SQB 10-2142 2 Hood Casing
CH0048SQB 10-2148
3 Control Unit C1-0501-0101
4 Control Board C1-0404-0401-A
5 Halogen Light Unit (12V 20W Max.) C1-0403-0101
6 Motor B001-4.5
7 Lamp Socket Cover C1-0204-2130
8 Lamp Socket C1-0414-0120
9 Safety Screen B001-4.2
CH0030SQB C1-0201-2130
CH0036SQB C1-0201-2136
CH0042SQB C1-0201-2142 10 Capacitor Panel
CH0048SQB C1-0201-2148
CH0030SQB
CH0036SQB
C1-0402-0120-4
CH0042SQB
11 Transformer (Light)
CH0048SQB
C1-0402-0120-60
12 Capacitor C1-0401-0120-03
13 Transformer (Motor) C1-0402-A-120-01
14 Processor Board Box C1-0501-0102
15 Processor Board C1-0404-0401-B
16 Screw (1/8” x 3/8”) C1-0708-0003
17 Baffle Filter B101-2130-15
Bottom Casing
4” Wide
CH0030SQB
CH0036SQB B101-2130-09
4” Wide
3” Wide
CH0036SQB B101-2136-09
5-1/4” Wide CH0042SQB B101-2142-09
18
A
B
C
D
4-1/2” Wide CH0048SQB B101-2148-09
BLOWER ASSEMBLY
NO. DESCRIPTION MODEL /SIZE PART NO.
6-1 Screws (3/16” x 3/8”) B001-4.1
6-2 Left Locknut B001-4.3
6-3 Left Squirrel Cage B001-4.4
6-4 Right Squirrel Cage B001-4.6
6-5 Right Locknut B001-4.7
6-6 Air Chamber B001-4.8
ORIGINAL KIT
NO. DESCRIPTION MODEL /SIZE PART NO.
01 Hood-Mounting Bracket C1-0221-0330
02 Screw (3/16” x 3/8”) C1-0707-0001
CH0030DC-12 B102-6012-030
CH0036DC-12 B102-6012-036
CH0042DC-12 B102-6012-042 03 Duct Cover
CH0048DC-12 B102-6012-048
02 Screw (3/16” x 3/8”) C1-0707-0001
