36 PLAYBACK – BASIC OPERATION
PLAYBACK – BASIC OPERATION
Single-frame playback display
Images can be viewed in the Quick View or playback modes. This section covers the basic
operation in both modes. The playback mode has additional functions, see page 68.
Mode indicator
Time of recording
Date of recording
Lock indicator (p. 72)
Magnification display (p. 39)
Image-size display (p. 48)
Image-quality indicator (p. 48)
Battery-condition indicator (p. 16)
Frame number/total number of images Audio-track indicator
DPOF-set indicator (p. 72)
Folder number – file number (p. 92)
E-mail copy indicator (p. 72)
To view images from the playback mode, turn the mode
dial to the playback position.
To view images from the recording or
movie/audio recording mode, press the Quick
View/Delete button.
