3 Before making copies
3-38 bizhub 162/210
Copying onto manually fed paper by multi bypass tray
1
Position the documents.
For details refer to “Loading the document” on page 4-10.
2
Adjust the bypass tray extender and
the paper guides to fit the size of the
paper.
3
Load the paper with the front side
facing down, lightly sliding the paper
as much as possible into the feed
slot.
The manual bypass mark ( ) ap-
pears in the bottom line of the
screen.
? Are sheets of cards or postcards loaded?
% Make sure that they are not curled (rolled).
4
Check that YES/NO appears in the
bottom line of the screen, and then
press the [No/C] key.
YES/NO is displayed for approxi-
mately 5 seconds after paper is load-
ed into the multi bypass tray. The
paper source setup menu appears.
5
Press the [
*] and [)] keys to select
the type of paper loaded.
Select from the following four paper
type settings.
PLAIN
OHP
CARD
ENVELOPE
6
Press the [Yes] key.
The paper size menu appears.
