REGISTRATION/ADU/REVERSE/PAPER EXIT
CF5001 Ver.1.0 Sep. 2003
2-46
II UNIT EXPLANA
TION
11. REGISTRATION/ADU/REVERSE/PAPER EXIT
11.1 Composition
Symbol
Name
Function or method
[1]
ADU conveyance roller /2
Paper conveyance while in the double side copy mode and
loop formation for the correction of paper skew correction
Motor drive
[2]
ADU reverse roller
Paper conveyance in the ADU reverse section and switching
of the conveyance path
Motor drive
[3]
Reverse/exit roller /2
Paper conveyance in the reverse section
Motor drive
[4]
Paper exit roller
Paper conveyance in the paper exit section
Motor drive
[5]
Reverse gate
Switching of the paper exit path at the fixing unit exit section
Solenoid drive
DRIVE
CLOCK
F/R
LOCK
H/L
DRIVE
M41
MC4
HV2
A
A
B
B
M34
MC5
MC3
MC1
MC2
M31
A
A
B
B
M32
A
A
B
B
M33
A
A
B
B
M30
A
A
B
B
SD4
PS24
[1]
[21]
PS23
PS22
PS28
PS24
PS55
PS27
PS21
PS20
PS19
PS12
PS13
[2]
[3]
[4]
[5] [6] [7] [8] [9] [10] [11]
[13] [14]
[12]
[15] [16] [17] [18] [19]
[20]
8050ma2022
CVDB
PRCB
