BAC-10000 Series 8 Operation Guide, Rev. J
(Advanced) Temp. Setpoint Limits
LIMITS
OCC MIN CLG:
OCC MAX HTG: 76° F
UNOCC MIN CLG: 77° F
UNOCC MAX HTG: 65° F
71° F
To set the minimum and maximum allowed user/
operator setpoint values, press:
1. Up/Down to move among entries.
2. Enter to select.
3. Right/Left to move among value fields.
4. Up/Down to increment/decrement value.
(Advanced) Motion Sensor
MOTION SENSOR
MOTION OCC:
STATE: OCCUPIED
ENABLE
In BAC-11xxx models, a motion/occupancy sensor
may be enabled to trigger occupancy override.
During scheduled “off” times, the motion sensor will
start occupancy override (for 1 hour as a default)
when it detects motion. Occupancy override will end
(with the default setting) 1 hour after motion was
last detected. The length of occupancy override is
configurable in the System menu. See System Setup
on page 13 .
To enable/disable or monitor the motion/occupancy
sensor (if installed), press:
1. Enter to select.
2. Right/Left to move among value fields.
3. Up/Down to increment/decrement value.
The State field monitors whether motion has been
detected during the last scan of the motion sensor
input (BI6). Detected motion will show an “occu-
pied” state. This can be used during troubleshooting
to determine if motion is being detected.
(Advanced) BACnet Device Properties
DEVICE
INSTANCE:
NAME: FlexStat_101
LOCATION: KMC Controls
RESTART: NO
RESTORE FACTORY: NO
1
To set the BACnet device instance, name, and
location, press:
1. Up/Down to move among entries.
2. Enter to select.
The FlexStat can also be restarted or restored to
factory defaults from this menu. See Resetting the
FlexStat on page 14 for more information about that
function.
(Advanced) Inputs
INPUTS
1: SPACE TEMP
2:
3: MIXED AIR TEMP
4: OUTSIDE AIR TEMP
4: SPACE HUMIDITY
DISCH AIR TEMP
INPUT #2
DISCH AIR TEMP
VALUE: 60.0° F
CAL. OFFSET: 0.0
OUT-OF-SERVICE: FALSE
SENSOR: 10K TYPE III
Inputs vary according to model, selected application,
and selected application options. See (Advanced) Ap-
plication Options on page 5 .
To change sensor type and calibration offset, press:
1. Up/Down to move among entries.
2. Enter to select.
3. Right/Left to move among value fields.
4. Up/Down to increment/decrement value.
Value will show a temperature reading or a voltage
(0.0 to 3.0), depending on the sensor. Analog sensors
can be calibrated using the Calibration Offset option.
