BAC-10000 Series 11 Operation Guide, Rev. J
Date/Time
DATE/TIME
DATE:
TIME: 1:43:59 PM
APR 11 2009
To enter date and time information (only), press:
1. Up/Down to move among entries.
2. Enter to select.
3. Right/Left to move among value fields.
4. Up/Down to increment/decrement value.
More options (such as UTC offset and daylight sav-
ing time options) are available in the (Advanced)
Date/Time menu (see page 7 ).
Alarms
SAT 4/11 3:20 PM
COOL:
OCC:
FAN:
SERVICE HUM: 20%RH
ALARMS
* SPACE TEMP ALARM 04/11
04/11/09 08:37:56
SPACETEMP
PRESENT VALUE = 90.1
EXCEEDS HIGH_LIMIT
SPACETEMPALARM
DELETE ALARM?
NO YES
A flashing “SERVICE” on the Home screen indicates
an alarm. To view and delete alarms, press:
1. Right to move among fields.
2. Enter to select. (Enter on Alarm Details screen to
delete the alarm.)
3. Left to go back one page.
Built-in alarms are triggered under these conditions:
• Space Temp Alarm—temperature outside the
range of 56 to 86° F for over 300 seconds.
• Space Humidity Alarm—humidity above 65%
for over 300 seconds. This is available only in
FlexStat models with a humidity sensor and a
dehumidification option selected in the Humid-
ity setup). See Humidity Setup on page 5 .
• Fan Fail Alarm—no fan status signal within five
seconds of call for fan (and Input 2 is configured
for the fan status sensor option). See Sensor Setup
on page 6 .
• Low Limit Alarm (freeze stat)—space
temperature is below the adjustable (under
Damper Setup) low limit alarm temp for one
second (when configured for the economizer
option). After a low limit alarm is generated,
the fan will not run until after the FlexStat
is restarted. See Restart under Resetting the
FlexStat on page 14 . See also Damper Setup on
page 5 .
(Up to six additional alarms may be added with
custom programming.)
NOTE: Time delays and limits can be modified in
the corresponding Event Enrollment objects
using TotalControl.
