BAC-10000 Series 4 Operation Guide, Rev. J
Configuration (Initial Setup)
NOTE: Menus shown in this document reflect
firmware version R1.3.0.4 or later. Actual
context-sensitive screens are dependent
on firmware version, FlexStat model, and
options selected.
NOTE: If appear at the top of the screen
(such as in the Main Menu), scroll up or
down to see the rest of the menu’s off-
screen choices.
Main Menu Overview
MAIN MENU
ABOUT
ADVANCED
ALARM
DATE/TIME
SCHEDULE
SETPOINTS
SYSTEM
Navigate the menus and change settings by pressing
a combination of buttons. Press the:
• Enter button to select and/or exit value editing.
• Up/Down button to move among entries (up/
down lines).
• Left/Right button to move among value fields
(left/right spaces).
• Left button to return to the Home screen.
NOTE: A log-in may be required to access menu
items.
SETPOINTS
COOL SETPT:
HEAT SETPT: 67° F
COOL SETBACK: 80° F
SAVE CHANGE?
NO YES
When prompted about a change (on any menu),
press Right/Left to select the desired choice and
then Enter.
About the FlexStat
ABOUT FLEXSTAT
FW: R1.3.0.0
BUILT: DEC 11 2009 @13:55:07
ASV: BAC_1xx63 R1.3.0.0 +6
MODEL: BAC–11163C
APP: AIR HANDLER
OPT: MOD H / MOD C
INSTANCE: 1
This display-only screen shows (scroll to see all):
• Firmware version (FW)
• Build date
• Application software version (ASV)
• Model number
• Application configuration and options (set in the
Application menu)
• Device instance (set in the Device menu)
• MAC address (set in the Communications menu)
• Serial number
• Board revision
NOTE: ASV will show CUSTOM if any built-in
Control Basic program (1–5) is not running
or has auto-run disabled.
