BAC-10000 Series 22 Operation Guide, Rev. J
Firmware Upgrade
The existing version of firmware can be viewed from
the About the FlexStat screen. (See About the Flex-
Stat on page 4 ).
Firmware in the FlexStat can be upgraded using
a PC and a KMD-5699 firmware flash upgrade kit
available from KMC Controls. (For full upgrade
instructions, see the KMD-5699 Installation Guide,
P/N 913-019-04.)
Programming (Custom)
The FlexStat has a library of built-in applications and
options that are configured through the FlexStat’s
display. Beyond these standard configurations, cus-
tom changes can be added to a FlexStat using KMC’s
BACstage (ver. 2.4.0.26 or later) or TotalControl (ver.
2.0.5 or later). See the BAC-10000 Series Application
Guide (P/N 913-019-03) for more information.
NOTE: Customized programs are the responsibility
of the user. KMC Controls does not provide
support for such programs.
Maintenance
Remove dust as necessary from the holes in the top
and bottom. Clean the display with soft, damp cloth
and mild soap.
To maintain maximum sensitivity of optional built-in
motion sensors, occasionally wipe dust or dirt off the
lens—but do not use any fluid on the sensor.
HMO-10000 Horizontal or 4 x
4 handy box wall
mounting plate,
light almond
HMO-10000W HMO-10000 in
white
HPO-0044 Replacement cover
hex screw
KMD-5567 Network surge
suppressor
KMD-5575 Network repeater/
isolator
KMD-5576 EIA-485 to USB
Communicator
KMD-5624 PC data port
(EIA-485) cable
(FlexStat to USB
Communicator)—
included with the
KMD-5576 (buy for
third-party EIA-
232 interfaces)
KMD-5699 FlexStat firmware
flash upgrade kit
SP-001 Flat blade and hex
end screwdriver
(with KMC logo)
for cover hex
screws
XEE-6111-040 Transformer, 120-
to-24 VAC, 40 VA,
single-hub
XEE-6112-040 Transformer, 120-
to-24 VAC, 40 VA,
dual-hub
Accessories
